Friday, February 16, 2018

A Test That Turns Into A 2 Hour Imaging Session!

I headed out to the obs with only the thought of breaking out my old Canon XS camera body that I had modded a few years back but was never satisfied with the results I got.
Since then I came to understand that the problem was that I was shooting on .jpg images, which are terrible to work with in astrophotography. RAW images, I learned, gave more latitude in adjusting colors, color balance and contrast.
So I thought I would take advantage of clear skies (which were going to get clouded over shortly) and run a few image tests with it... then get back indoors for the rest of the evening.
WRONG!
After a few shots and a brief effort at post-processing... I was hooked for two hours until the clouds started covering my subjects!
WOW, the images were impressive! And though I don't think the samples in this blog are anything like what they will be in the future (with more subs and better focus and more experience in post-processing) I was elated with the "test" results.

The first test shot was of the Orion Nebula (M42) region of the Orion constellation (which is in the southern evening sky now).
Wow! The reds just popped out! And a 3 minute exposure was all that was needed! Hit that EASY button!

What immediately captured my attention was the brevity of the exposures to grab the reddish portion of the nebula. In previous attempts over many years, the blues of the nebula stood out and the reds were harder to image unless I spent a lot of time with lots of sub-exposures. But because the camera was modded (the infrared blocking filter removed from the camera) the reds just plain POPPED out!
And that in just a few minutes compared to many times more than that in previous imaging sessions!
In fact, so much red that I had to combine the result with non-ir images to bring out the blues!

So I thought I would head on over to the Rosetta Nebula (just to the left of Orion). The previous night I had tried to image it only to be so disappointed in not capturing it that I didn't bother to post it on this blog. But just a 3 minute exposure with the modded camera and WOW! There it was!

Whoohoo! Hit that EASY button again!

And then, with clouds threatening, I slewed back to Orion, to the area of the star Alnitak and gave the Flame Nebula and the Horsehead Nebula a go.
Never before had I EVER captured the Horsehead Nebula with its deep reds without hours and hours of effort... and this was just a 3 minute sub! Hit that EASY button again and again!
Lessons learned:
1. An IR modified Canon camera body... DON'T LEAVE HOME WITHOUT IT !
2. Shoot RAW or else go home!
3. Stack "normal" white balance images with the modified IR images to bring out all the colors!
4. Use the live stacking program AstroToaster to quickly live stack the images

Wednesday, February 7, 2018

Another try at Barnard's Loop in Orion WITH a guide camera!

Another clear evening (that's two in a row!) Out to the obs for some more tests with a new guide camera my wife got me for Christmas, an Astromania SGCMOS through Amazon. First time to really use it and WOW!!  Long exposures (6 plus minutes) with no star trailing... and I haven't found the upper limit of length of exposure yet!


This is a SINGLE image using an old Canon 40D camera with some post processing using GIMP, Luminar, and Preview.

Wide field image of the region of the constellation Orion. Showing Barnard's Loop, the Great Orion Nebula, the Flame nebula, the Horsehead nebula and a touch of the Wizard's nebula (far right).

Info: Canon 40D camera (NOT modified), ISO 200, 50mm lens set at f/4, 6 minute exposure, piggy-backed on a Meade LX200GPS 8" equatorially mounted scope, guide scope 50mm, guide camera is an Astromania SGCMOS (from Amazon).

Tuesday, February 6, 2018

Barnard's Loop in Orion

Clear skies in La Pine, and you know what that means: astrophotography! The region around the constellation Orion was my focus last night. That faint reddish cloud at the left is part of what is called Barnard's Loop.



It was hard to bring out Barnard's Loop in post-processing but I got as much as I could without totally messing up the rest of the nebula, especially the Great Orion Nebula.

EXPOSURE info: 35 minutes total exposure time (about 75 - 30 sec subs), Canon T3i, 40mm lens set at f/4, tracking via Celestron 4SE mount, DeepSkyStacker, post-processed using GIMP (https://www.gimp.org/)

Wednesday, January 31, 2018

Initial post on today's total eclipse of the "blue-blood-super" Moon

It cleared up long enough to capture the first half of the total lunar eclipse here in central Oregon!
I will write more in a later post but I just wanted to get these images posted right away.
These were taken from the edge of "down town" La Pine, looking across a large meadow to the west. It was 21 degree F and very still. It was a beautiful scene... until the fog rolled in from the north.
Enjoy God's creation!

Prior to totality (exposure to reveal the dark shadowed area)

At totality (it was actually quite dark!)

This image has the star cluster M44 there on the right.




Monday, January 29, 2018

More Preparation for Wednesday's Total Lunar Eclipse

I needed clear skies to take two more test images of the full Moon in preparation for Wednesday, January 31, 2018 total eclipse of the Moon.

The first image test was to attach my Canon T3i to my Daystar 500mm f/6 scope (from the CATE Total Solar Eclipse Experiment).

This is much nicer image size and better clarity than the 400mm scope I tested yesterday.

The second image test was an early submission for an experiment to make a 3D image of the Moon tonight and (hopefully) for Wednesday morning's total eclipse of the Moon (weather permitting here). Images will be take over 500 miles apart (maybe more) with the exact same experiment by different CATE volunteers, one being in the San Diego, California.

Here are my early submissions to this test. The first is the focus image. The setup was a Daystar 500mm f/6, PointGrey monochrome 5mp camera, Celestron CG-4 mount taken at 8 pm, January 29, 2018.

The second is an HDR composite image.

The last is a post-processed image to bring out some contrast.

So it appears that my primary scope is going to be the Daystar 500mm f/6, which I will use with both the monochrome PointGrey camera and my color Canon DSLR T3i camera.

I will still take a few image with a second Canon camera for "context" images.

Preparing for the Blue-Blood Moon Lunar Eclipse...

This Wednesday's full moon is unusual:

First, it is the SECOND full moon in the month of January, 2018. As such it is commonly referred to as a "blue moon", where we get the expression "once in a blue moon" because it is a fairly rare event to have two full moons in a given month.

Secondly, this full moon is graced with being a total lunar eclipse, which is when the Moon passes behind the Earth and enters its shadow cast by the Sun.

Here in Oregon it will occur early Wednesday morning from about 4 am until 6 am, due west. You will need to have a fairly clear view of the horizon to see it, though, as it will begin about 30 degrees above the horizon and drop during totality all the way down to about 5 degrees above the horizon.

Thirdly, and here is the "joke":
Question: When is a "blue moon" NOT a "blue moon"?
Answer:   When it is a "blood moon"!
In other words, when the Moon dips into the shadow of the Earth, the color of the light bending will shift slowly from yellow, orange, brownish and even "blood" red.

PREPARING to IMAGE this LUNAR ECLIPSE:

In preparation for this Wednesday morning's total lunar eclipse I have been testing various lens and telescopes to get a better idea as to how large the Moon will appear in the images I take with a Canon T3i DSLR camera body.

The good news is that the totality of a total lunar eclipse lasts a very long time (up to several hours) compared to a typical total solar eclipse (only about 2 to 6 minutes). This allows one to be able to change the lens/telescope at will once totality occurs.

And it is not always desirable to image the Moon as large as possible in the image. If one includes some foreground objects (trees, buildings, statues, clouds, etc) one may want to use a lens of much lower power to capture the context of the eclipse, as these images (taken by others, not myself) show:

(I would give photo credits but these were posted on the web without them)

PROBLEM:
Since the Canon T3i is a "cropped sensor" camera, the typical focal length measurements do not line up with what one could expect with an old fashioned 35mm camera lens chart. Hence the need to test my various lenses and telescopes to get a better idea of what size the Moon will appear in the final images.

Here are the 5 lenses and telescopes that I expect to use, weather-permitting, this Wednesday:

250mm focal length: Canon 55-250mm zoom lens (f/4.5-5.6)



350mm focal length: Tele-Lentar film camera telephoto (f/5.6)


400mm focal length: Celestron Short Tube (70mm f/5.7) OTA


750mm focal length: Celestron C-5 telephoto (127mm f/6 Cassegrain) OTA


1,350mm focal length: Celestron NexStar 4 SE (102mm f/13 Maksutov-Cassegrain) OTA


So I tested these in poor weather conditions last night (lots of clouds, but some thin enough to see the Moon) with the camera and lenses/telescope on a stationary tripod: Here are the results without cropping the images:

250mm:

350mm:

400mm:

750mm:

1,325mm:
(the clouds really got thick when I took this shot!)

RESULTS:
As you can see, the NexStar 4SE (1,325mm) telescope did not quite take in all the Moon, which may not be useful except in the earlier pre-totality phases of the eclipse.

The 400mm and 750mm images point to the Celestron C5 and the Celestron Short Tube as being the best overall for as telephoto as possible with what I have.

There is one more scope I may use which will be about 500mm, a Daystar telescope used in the CATE project, that I hope to test tonight and update this page afterwards.
Daystar 500mm telescope

However the 350mm, though not as telephoto seemed to create a sharper image with more control over the f/stop by use of its diaphragm settings.

The much wider view that the 250mm telephoto zoom lens offers will likely be the one I use to put the eclipse "in context" of the foreground mountains, trees, etc.

WEATHER FORECAST:
Now I just need clear skies in the area of the Moon on Wednesday from 3 am until 6 pm, though the present weather forecast is foreboding...
Tuesday over night forecast:

Wednesday morning forecast:



Saturday, January 13, 2018

Surprised by mostly clear skies... A Comet and a Nebula



The Flame Nebula (aka NGC 2024 & Sh2-277)
located just to the left of the left hand star (Alnitak)
in Orion's Belt.
Meade LX200GPS 8" f/10 - prime focus- Canon T3i
ISO 12800 - 7 45 sec exposures stacked with DSS
for a total time of just over 5 minutes

Last night was a surprise... the skies cleared up a bit.
So it was out to the obs to do some tests with my Christmas present: a guiding camera.
I still have to find out why PHD2, while recognizing the camera, will not connect to it.
All the same I managed to eck out a few images, though not as many as I needed to get good clean images. Yeah, I was really pressing it to attempt to use the big scope at prime focus instead of using a focal reducer. Live and learn!

A comet is visible in the night sky near the head of Taurus, the Bull, on its way to the Pleiades.
It is Comet PanSTARRS C/2016 R2.


This image is cropped down and tilted so as to compare it with the next image that was taken with a better setup than mine. You will notice that the comet's tail is not in a typical straight line behind the comet's head. This comet is making some unusual tails in the past few days and I was glad to capture it even if it isn't all that well defined.



The next image Amateur astronomer Gerald Rhemann took from his private observatory in Farm Tivoli, Namibia taken the same night as mine. It is a 56 minute guided exposure through a 12-inch telescope that shows the same "dog-leg" break in the comet's tail.



Tuesday, January 2, 2018

2017 Year in Review Photo poster


2017: 47 blog posts

First Full Moon of January 2018

This month is unique in the sense that January will have not one but two full Moons!
Fortunately the skies held clear long enough (January 1, 2018 at 7 pm PST) to take this shot.
Almost immediately after freezing fog began to flow quickly across the sky!
Happy New Year, one and all, and may the Lord bring His blessings into your life!
